| · Pure laser solid-state light source, long life of 20,000 hours · 3600 lumens, 100000:1 high contrast · 0.233:1 ultra-short throw ratio, projection 100" (16:10 ratio) only needs 1250px (projection lens to projection screen distance) · Rich and complete interface: HDMI 2 group / VGA2 in 1 out / RJ-45 / RS-232 / USB direct reading / audio and other interfaces · 1 set of 3D synchronous interface, support VESA 3D · 1 set of 5V power supply interface, can provide USB power supply · Optional automatic protection sensor to protect the eyes · Optional built-in interaction for interactive functionality without an electronic whiteboard |
Product Features
◆Laser solid state light source with over 20,000 hours of life
With a laser solid-state light source, the life of the light source exceeds 20,000 hours, which greatly saves user's cost.
◆Support stand-alone 3D stereo projection
Using DLP Link technology, supporting 120HZ signal output, single projector can realize 3D stereo projection and Blu-ray 3D direct reading, which makes courseware demonstration more vivid. Built-in 3D SYNC synchronization interface, connected to external 3D synchronization device, resulting in a more stable 3D experience.
◆0.233:1 ultra short-focus lens design
Only 1250px (projection lens to projection screen distance) can project 100" (16:10 ratio) large screen; it will not be blocked by light when actually used, combined with animated reflection effect, effectively protect vision, and no radiation risk
◆Strict heat dissipation, power supply, dust-proof design to ensure product quality
High-quality power supply components are used to ensure stable operation of the projector for a long time; the large-area metal heat-dissipating scales are specially built in the body to ensure the normal heat dissipation of the whole machine and reduce noise effectively; the high-efficiency sponge dust-proof net effectively extends the life of the projector, to ensure the quality of the projector is stable.
◆Automatic protection sensor
A protective sensor can be installed next to the projector lens. When someone approaches, the sensor will automatically detect the human body and automatically turn off the light source to prevent the laser source from directly shining both eyes and protecting the eyes.
◆Optional built-in original factory interactive module
Built-in intelligent interactive module, interactive projection function can be realized without electronic whiteboard, touch screen function can be realized by interactive pen on projection screen; multi-touch can be supported, and functions such as zooming and rotating can be performed; Function, providing multi-person collaborative split screen operation space.
Technical Parameters
Type | SW536+ | |
Technology | Display Technology | 0.65” DLP WXGA (1280 x 800) |
Brightness | ANSI Lumens | 3600 |
Contrast | Contrast | 100000:1 |
Lamp | Lamp Power；Lamp Life Time(H) | Laser solid state light source； ≥20000H |
Projection lens | Throw Ratio | 100”@50cm；0.233：1 |
Zoom Ratio | 1.0x | |
Screen size | 80''~120‘’ | |
Noise | Noise(dB)@1m | economic mode: Max 30dB；standard mode: 35dB |
AR | Aspect Ratio | 16:10 (standard)/ 4:3 16:9(compatible) |
Input | VGA | *2 |
Audio in（mini jack,3.5mm） | *1 | |
YCbCr/Component | N/A | |
Video | *1 | |
Audio in（L/R）RCA | *1 | |
S-Video S | N/A | |
HDMI | *2 | |
USB-A | *1(5V powered by) | |
MIC | *1 | |
Output | VGA computer output | *1（share with input 2） |
Audio out（mini-jack,3.5mm） | *1 | |
Control | RS232 | *1 |
RJ45 | *1 (used to control) | |
USB-B | *1(used to update) | |
3D VESA SYNC | *1 | |
Audio | Speaker | 1*10W |
Power | Power Requirements | 100~240V@ 50/60Hz |
Power Consumption | <250W，<0.5W（Standby mode） | |
Dust-proof | Dust filter | High density sponge dust filter |
Keystone | Keystone Correction | V:±40°（manual） |
OSD menu | Languages | English |
Volume | (WxHxD)（mm） | 446x370x140 |
Weight | Net. Weight (kg) | 9.6 |
