| · 3LCD technology，Balance Brightness and color, high contrast and high uniformity. · 20,000 hours of long lamp life, no light door design and maintenance is easier · A variety of powerful keystone correction functions such as vertical and horizontal and four-corner correction technology for perfect projection · Rich and complete interface：with 2* HDMI（one of them support with MHL）/VGA/ RJ-45/ RS-232/ USB/other video and audio interface. · USB-A 2.0 interface, support USB power supply and U disk direct reading · USB-A 2.0 interface, support for optional WIFI wireless module for wireless projection, support for Airplay & Miracast with the same screen mirroring function · RJ45 network cable is connected to the direct projection screen, and can control the projection function. · Automatic signal search, automatic keystone correction · Automatically recognize the front or ceiling status and automatically adjust the screen · 100/200/300 hour automatic filter cleaning reminder · 0/60/90sdefinable cooling time shutdown, the fastest 0 seconds shutdown. · Automatic call power on function · Up to 26 countries menu languages are available. |
Product Features
◆Up to 20,000 hours of lamp life
Using Philips' latest 225w long-life bulb, it can last up to 20,000 hours in energy-saving mode, and it can reach 10,000 hours in standard mode , which greatly saves the user's cost; the appearance ID adopts no lamp-door design, the appearance consistency is higher, and the maintenance is easier.
◆Correction function
Manual and automatic vertical keystone correction with horizontal keystone correction. Besides, providing Corner Keystone、Pincushion/Barrel Correction.Maximizes the user's ability to achieve excellent imaging on the uneven projection surface.
◆A variety of humanized design
High-density electrostatic dust-proof net can filter dust better, which extend the life of the projector effectively , and ensure the quality of the projector stable. When using 100/200/300 hours, it will automatically prompt the filter to clean the machine.Definable shutdown cooling time, the fastest 0 seconds to shut down, you can set the 0/60/90s to be off.
Supporting high altitude mode,and the projector can work normally at 1400-2700m high altitude.
◆Double password lock and double anti-theft function
With user power-on password protection and keyboard or remote control lock function, which avoid projector error operation and theft. In addition, the projector is equipped with a Kensington lock slot
and an anti-theft lever, which can be attached to the projector to prevent theft.
◆ Menu support 26 countries languages
Offering up to 26 countries menu languages, it has many international certifications such as CB/CE/FCC/cTUVus/CCC/CECP.
Technical Parameters
Type | MX442 | |
| Display Technology | Liquid Crystal Display 3x0.63” XGA (1024x768) |
| Brightness( ANSI Lumens )＊ | 4200 |
| Contrast | 15000:1 |
Lamp | Lamp Power；Lamp Life Time(H) | Philips:225W； 10000H(standard mode) /20000H(economic mode) |
| Throw Ratio | 70"@2.1m；1.48~1.78：1 |
Zoom Ratio | 1.2x Manual | |
Screen size | 0.888~10.937m（30"~300"） | |
Noise | Noise(dB)@1m | economic mode: 33dB；standard mode: 37dB |
AR | Aspect Ratio | 4:3 (standard )/16:9(compatible) |
Input | VGA computer input | *1 |
Audio in（mini jack,3.5mm） | *1 | |
YCbCr/Component | N/A | |
Video | *1 | |
Audio in（L/R）RCA | *1 | |
S-Video S interface | N/A | |
HDMI 1.4 | *2 | |
USB-A 2.0 | *1 （1）5V /1.5A powered by; （2）U disk direct reading； （3）Wireless display, support Airplay & Miracast with the same screen mirroring function (additional purchase optional wireless module） | |
USB-B | *1（display function） | |
RJ45 | *1（display function） | |
Output | VGA computer output | *1 |
Audio out（mini-jack,3.5mm） | *1 | |
Control | RS232 | *1 |
RJ45 | *1 ((for non-client upgrades)) | |
USB-B | *1((for non-client upgrades)) | |
Other Interface | N/A | |
Audio | Speaker | 1*10w |
Power | Power Requirements | 100~240V@ 50/60Hz |
Power Consumption | 310w（standard）/217w（economic），<0.5w（standby mode） | |
Dust-proof | Dust filter | ESD filter |
Keystone | Keystone Correction | V: ±30°（auto+ manual）H：±15°（manual） |
OSD Menu | Languages | Support 26 language |
Volume | V(WxHxD)（mm） | ~345*261*101 |
Weight | Net. Weight (kg) | ~3.3 |
＊Based on the ISO21118 standard, this nominal value represents the average value of the product at the time of production, and the factory minimum value of the product is 80% of the nominal value.
The design, functions and specifications of this projector are approximate values, and HengSheng guarantees the right to change.
